RZR XP TURBO
Engine Type 4-Stroke DOHC Twin Cylinder
Cylinders-Displacement (cc) 999 cc
Transmission/Final Drive Automatic PVT P/R/N/L/H
Fuel System Electronic Fuel Injection
Drive System Type High Performance True On-Demand AWD/2WD
Cooling Liquid
Engine Braking System (EBS) Not Equipped
Active Descent Control Not Equipped
SUSPENSION
Front Suspension Dual A-Arm Walker Evans 2 Needle Shocks (comp adjust/res.) 16" (40.6 cm) Travel"
Rear Suspension Trailing Arm Walker Evans 2.5 Needle Shocks (comp adjust/remote res.) 18" (45.7 cm) Travel"
BRAKES
Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front & Rear Calipers
Parking Brake Park in Transmission
TIRES / WHEELS
Front Tires 29 x 9-14; Maxxis Bighorn
Rear Tires 29 x 11-14; Maxxis Bighorn
Wheels Cast Aluminum
DIMENSIONS
Bed Box Dimensions (L x W x H) 30 x 22 x 7 (72.0 x 57.0 x 17.8 cm)"
Front/Rear Rack or Box Capacity N.A./300 lb (136.1 kg)
Fuel Capacity (Litres) 9.5 gal (36 L)
Ground Clearance 13.5 (34.3 cm)"
Overall Vehicle Size (L x W x H) 119 x 64" x 73.75" (302.2 x 162.6 x 187.3 cm)"
Payload Capacity 740 lb (335.6 kg)
Person Capacity 2
Wheelbase 90 ( 228.6 cm)"
Estimated Dry Weight (pounds/kg) 1,379 lbs (625.5 kg)
FEATURES
Cargo System Lock & Ride
Color / Graphics White Lightning
Electronic Power Steering Standard
Hitch Towing Rating N.A.
Hitch Type None
Instrumentation Digital Gauge: Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light; DC Outlet
Lighting White LED, High/Low & Red LED Tail/Brake Lights
Unbraked Trailer Towing Capacity N.A.
